Glyphcast

Convert videos into ASCII sequences.

Browser-native ASCII studio for image, GIF, and video workflows.



About The Project

Glyphcast is an interactive studio that converts visual media into animated ASCII output.
Each frame is sampled on a pixel grid, mapped to a character set by luminance, styled with typography/effects, and rendered in real time for preview and export.

The studio supports:

• source uploads (image, GIF, video)
• live preview and playback controls
• editable charset, columns, threshold, invert, and appearance controls
• multiple export formats for design, code, and content pipelines

Project Preview

Add your video file to assets/site and update this link path when ready.

Core Features

• Real-time ASCII conversion with adjustable columns and threshold
• Rich charset presets (Standard, Retro Terminal, Matrix, Binary, and more)
• Appearance controls for font family, size, spacing, colors, and text effects
• Playback/scrubbing for animated sources (video and GIF)
• Built-in exports:
  • PNG snapshot
  • video export (browser MediaRecorder, MP4/WebM support depending on browser)
  • React component (.tsx) export for embedding generated animations
  • ZIP export of per-frame text files
  • one-click copy of current ASCII frame to clipboard

How Conversion Works

Glyphcast’s conversion pipeline is implemented in src/lib/ascii/ascii-converter.ts and src/lib/ascii/ascii-export.ts.

1. Resolve source dimensions (image, video, or canvas)
2. Downsample source to ASCII grid (columns x derived rows) on an offscreen canvas
3. Compute luminance using ITU-R BT.601 coefficients (0.299r + 0.587g + 0.114b)
4. Map luminance to charset index (with optional invert + threshold offset)
5. Build text frame and optional per-cell RGB colors
6. Render preview/export frames with appearance settings and optional effects

Studio UX Details

• Input types: image/*, video/*, and image/gif
• Upload limit: 30 MB max source file (intentional guardrail to prevent very large video/asset uploads in the browser studio)
• Default video behavior: auto-loads a demo clip in studio when no source is present
• Keyboard shortcuts:
  • Space → play/pause
  • Left / Right → frame step
  • Cmd/Ctrl + S → trigger export action

Tech Stack

• Next.js 16 (App Router)
• React 19
• TypeScript
• Tailwind CSS 4
• Framer Motion
• Zustand
• Radix UI primitives
• gifuct-js for GIF frame decoding
• fflate for ZIP frame exports

Project Structure

glyphcast/
├── assets/
│   └── site/                  # README/site branding assets
├── public/                    # static media, logos, preview clips
├── src/
│   ├── app/
│   │   ├── api/               # Next.js API routes (e.g. GitHub stars)
│   │   ├── page.tsx           # landing page
│   │   └── studio/page.tsx    # ASCII studio page
│   ├── components/
│   │   ├── animations/        # ASCII animations and shape variants
│   │   ├── landing/           # Landing page sections and UI
│   │   ├── providers/         # Global context providers (Theme, Studio)
│   │   ├── shared/            # Reusable components
│   │   ├── studio/            # ASCII Studio interface components
│   │   └── ui/                # Base design system components
│   ├── config/                # Site and SEO configurations
│   ├── data/
│   │   └── ascii-frames/      # JSON data for static ASCII animations
│   ├── hooks/                 # Custom React hooks
│   └── lib/
│       ├── ascii/             # Core ASCII conversion and export logic
│       └── store.ts           # global studio state (Zustand)
├── example.env
└── README.md

Configuration

Copy env values from example.env:

cp example.env .env

Environment variables:

• NEXT_PUBLIC_SITE_URL — base URL used by metadata routes
• NEXT_PUBLIC_GITHUB_REPO — repo slug in owner/name format

Getting Started

Prerequisites

• Node.js 20+
• Bun

Install and run

bun install
bun run dev

Open http://localhost:3000.

Available scripts

bun run dev
bun run build
bun run start
bun run lint
bun run format

Output Formats

• Image export: PNG of current rendered frame
• Video export: canvas-recorded animation (MP4/WebM depending on browser support)
• React export: generated TSX component with frame data + playback logic
• ZIP export: sequence of text frames (frame_0001.txt, etc.)
• Clipboard export: current frame plain text

Known Notes

• Video encoding capability depends on the browser’s MediaRecorder codec support.
• Large files and high frame counts increase export time and memory usage.
• The 30 MB upload cap is intentional so users cannot upload oversized videos/assets that degrade in-browser conversion performance.
• Browser permissions can block clipboard access.
