Pegasus Simulator

Pegasus Simulator is a framework built on top of NVIDIA Omniverse and IsaacSim. It is designed to provide an easy yet powerful way of simulating the dynamics of vehicles. It provides a simulation interface for PX4 and ArduPilot integration, as well as a custom python control interface. At the moment, only multirotor vehicles are supported, with support for other vehicle topologies planned for future versions.

Check the provided documentation here to discover how to install and use this framework.

Latest Updates

⚠️ For users of versions prior to v5.1.0: A new command line tool named isaac_run is now used to launch Isaac Sim. This is a function that should be added to your .bashrc or .zshrc file during the installation of Isaac Sim. See Installation Instructions for more details.

This was done to simplify the launching of Isaac Sim from the terminal with ROS2 support. All previous instructions that mentioned launching Isaac Sim examples from the examples folder using the ISAACSIM_PYTHON command should now use isaac_run instead.

Please refer to the updated documentation for more details.

• 2025-10-26: Pegasus Simulator v5.1.0 is released for Isaac 5.1.0. This version is NOT compatible with older versions of Isaac Sim. The Ardupilot experimental interface was not tested in this version. This update had an initial open-source contribution from Victor Kallenbach.
• 2025-10-25: Pegasus Simulator v4.5.1 is released for Isaac 4.5.0. This version is NOT compatible with older versions of Isaac Sim. The Ardupilot experimental interface was fixed and improved by Seunghwan Jo and Tomer Tiplitsky.
• 2025-07-20: Pegasus Simulator v4.5.0 is released for Isaac 4.5.0. This version is NOT compatible with older versions of Isaac Sim. The Ardupilot experimental interface was not tested in this version.
• 2024-11-01: Pegasus Simulator v4.2.0 is released for Isaac 4.2.0. This version is NOT compatible with older versions of Isaac Sim. This version includes a new experimental interface for Ardupilot integration, provided by open-source contributor Tomer Tiplitsky.
• 2024-08-02: Pegasus Simulator v4.1.0 is released for Isaac 4.1.0. This version is NOT compatible with older versions of Isaac Sim.

Citation

If you find Pegasus Simulator useful in your academic work, please cite the paper below. It is also available here.

@INPROCEEDINGS{10556959,
  author={Jacinto, Marcelo and Pinto, João and Patrikar, Jay and Keller, John and Cunha, Rita and Scherer, Sebastian and Pascoal, António},
  booktitle={2024 International Conference on Unmanned Aircraft Systems (ICUAS)},
  title={Pegasus Simulator: An Isaac Sim Framework for Multiple Aerial Vehicles Simulation},
  year={2024},
  volume={},
  number={},
  pages={917-922},
  keywords={Simulation;Robot sensing systems;Real-time systems;Sensor systems;Sensors;Task analysis},
  doi={10.1109/ICUAS60882.2024.10556959}}

Main Developer Team

This simulation framework is an open-source effort, started by me, Marcelo Jacinto in January/2023. It is a tool that was created with the original purpose of serving my Ph.D. workplan for the next 4 years, which means that you can expect this repository to be mantained, hopefully at least until 2027.

• Project Founder
  • Marcelo Jacinto, under the supervision of Prof. Rita Cunha and Prof. Antonio Pascoal (IST/ISR-Lisbon)
• Architecture
  • Marcelo Jacinto
  • João Pinto
• Multirotor Dynamic Simulation and Control
  • Marcelo Jacinto
• Example Applications
  • Marcelo Jacinto
  • João Pinto
• Ardupilot Integration (Experimental)
  • Tomer Tiplitsky
  • Tanner Gilbert
  • Seunghwan Jo

Also check the always up-to-date Github contributors list with all the open-source contributors.

Guidance, Control and Navigation Project

In parallel to this project, the Pegasus (GNC) guidance, control, and navigation project serves as the foundation control code for performing real-world experiments for my Ph.D. More information can be found at this link: Pegasus GNC

Project Roadmap

An high level project roadmap is available here.

Support and Contributing

We welcome new contributions from the community to improve this work. Please check the Contributing section in the documentation for the guidelines on how to help improve and support this project.

• Use Discussions for discussing ideas, asking questions, and requests features.
• Use Issues to track work in development, bugs and documentation issues.
• Use Pull Requests to fix bugs or contribute directly with your own ideas, code, examples or improve documentation.

Licenses

Pegasus Simulator is released under BSD-3 License. The license files of its dependencies and assets are present in the docs/licenses directory.

NVIDIA Isaac Sim is available freely under individual license.

PX4-Autopilot is available as an open-source project under BSD-3 License.

Project Sponsors

• Dynamics Systems and Ocean Robotics (DSOR) group of the Institute for Systems and Robotics (ISR), a research unit of the Laboratory of Robotics and Engineering Systems (LARSyS).
• Instituto Superior Técnico, Universidade de Lisboa

The work developed by Marcelo Jacinto and João Pinto was supported by Ph.D. grants funded by Fundação para a Ciência e Tecnologia (FCT).
